The digital livestock scale indicator provides a readable weight display for compatible weigh-bar and load-cell weighing systems. Designed for agricultural weighing applications, it combines an LCD, stainless steel housing, rechargeable battery, and practical weighing functions for managing cattle and other livestock.
When connected to properly installed and calibrated weigh bars, the indicator displays weight information that can help producers monitor animal growth, manage livestock weights, and maintain weighing records.
This indicator is a component of a weighing system, not a complete livestock scale. For compatible equipment, see Barn World's livestock chute scale weigh bars or browse our livestock scales and weighing equipment.
Digital Livestock Scale Indicator Specifications
| Digital Indicator Technical Specifications | |
|---|---|
| Display | LCD digital weight display |
| Housing | 304 stainless steel |
| Power | Rechargeable battery |
| Load Cell Excitation | +5 VDC |
| Load Cell Support | Drives up to four 350-ohm load cells |
| Internal A/D Resolution | 1:260,000 counts |
| Selectable Display Resolution | Up to 50,000 counts |
| Weighing Functions | lb/kg, zero, net, gross, tare and print |
| Status Indicators | Low battery, center zero, gross, tare, net, and stable |
| Additional Display Modes | Pieces, pounds, ounces, kilograms and percentage-related indications, as listed in the original specifications |
| Data Connection | Serial output described in the original listing for compatible external equipment |
| Dimensions | 9.0 inches × 5.5 inches × 2.9 inches |
Compatibility note: The original listing refers to an "RS-232" output, which may be a typographical reference to RS-232 serial communication. Confirm the actual port, communication settings, and cable requirements before connecting a printer, computer, or other device.
How a Livestock Scale Indicator Works
In a livestock weighing system, load cells measure the force applied to the weighing platform or chute. The indicator receives the electrical signals from the connected load cells and converts them into a weight reading.
The quality of the final measurement depends on the complete weighing system, including load-cell capacity, installation, mechanical stability, calibration and animal movement.
The indicator provides the display and control functions, but it cannot compensate for improperly installed weigh bars, binding equipment or an unstable platform.
Using the Indicator With a Cattle Chute
For cattle weighing, compatible weigh bars can be installed beneath an appropriate chute or weighing platform. The indicator is positioned where the operator can safely view the display and use the controls.
During weighing, allow the animal to settle as much as practical before recording the reading. Movement, contact with adjacent structures and uneven loading can affect measurement stability.
Keep the indicator and its cables protected from livestock traffic, pinch points and unnecessary impact.
Useful Weighing Functions
Gross Weight
Gross weight represents the total measured load on the weighing system before an applicable tare adjustment.
For example, a weighing platform may register the combined weight of the platform and the load unless the system has been zeroed or tared appropriately.
Tare and Net Weight
The tare function allows the operator to account for an existing load, such as a container or other supported weighing component, according to the indicator's operating procedure.
Net weight represents the measured weight after the applicable tare adjustment.
For livestock applications, the exact procedure depends on the platform or chute arrangement and the manufacturer's calibration instructions.
Zero Function
The zero function establishes or restores the appropriate unloaded reference within the indicator's permitted operating range.
Operators should follow the manual rather than repeatedly zeroing the scale to compensate for mechanical problems or an incorrectly installed platform.
Pounds and Kilograms
The indicator includes a lb/kg function, allowing weight readings to be displayed in either unit where supported by the configured system.
This is useful for operations that maintain records in different units or work with buyers, veterinarians and livestock programs that use different reporting standards.
Print Function
The listed print function supports use with compatible external recording equipment. Confirm the supported printer, interface cable and communication configuration before purchasing accessories.
Why Accurate Livestock Weighing Matters
Regular weighing can help cattle producers make better-informed management decisions. A properly configured scale provides objective measurements rather than relying entirely on visual estimates.
Potential applications include:
- Monitoring weight changes in growing cattle.
- Recording weights before marketing or shipment.
- Evaluating weight trends across feeding periods.
- Supporting livestock inventory and management records.
- Checking weights when animal handling procedures require measured information.
- Maintaining consistent records across multiple weighing sessions.
Weight readings are only as reliable as the scale installation and weighing procedure. Consistent animal handling, proper calibration and stable equipment are essential.
Rechargeable Battery and Stainless Steel Housing
The indicator includes a rechargeable battery, allowing operation without continuous connection to external power when the battery is sufficiently charged.
Battery operation can be useful in agricultural facilities where a permanent electrical outlet is inconvenient.
The stainless steel housing provides a durable enclosure suitable for demanding working environments. However, stainless steel construction alone does not establish a waterproof or weatherproof rating.
Protect the indicator from conditions outside its specified operating limits and follow the manufacturer's instructions for charging, storage and cleaning.
Connecting Compatible Weigh Bars
The indicator is listed as capable of driving up to four 350-ohm load cells with +5 VDC excitation.
This electrical specification is useful when evaluating compatibility, but it is not sufficient by itself to guarantee that a particular load-cell system will work correctly.
Before connecting equipment, confirm:
- Load-cell resistance and excitation requirements.
- Connector type and wiring configuration.
- Number of load cells used by the system.
- Combined load-cell capacity and platform design.
- Calibration procedure and available settings.
- Environmental protection for cables and connectors.
For a complete weighing installation, review the chute scale weigh bar system and confirm compatibility before ordering.
Digital Weight Records and External Connections
The original product description identifies a serial output for compatible computers or printers.
This type of connection can be useful when an operation needs to transfer or print weighing information rather than relying entirely on handwritten records.
However, successful integration depends on the indicator's communication settings and the receiving equipment. A physical connection does not automatically guarantee compatibility with a particular computer, printer or livestock management software package.
Confirm the interface specifications, available cables and supported data formats before planning an automated recordkeeping system.
Installation and Calibration Considerations
Accurate weighing requires correct setup of both the indicator and the mechanical weighing equipment.
- Inspect the weighing system. Confirm that the weigh bars, platform or chute are properly supported and free from mechanical interference.
- Check the connections. Verify that cables and connectors match the indicator and load cells.
- Position the indicator. Choose a protected location where the display is readable and controls are accessible.
- Configure the equipment. Follow the operating manual for the appropriate settings and measurement units.
- Calibrate the scale. Use the specified calibration procedure and suitable reference weights or methods.
- Test repeatability. Check that repeated measurements under controlled conditions produce consistent results.
- Establish a weighing routine. Use consistent procedures to reduce avoidable variation between sessions.
Do not assume the indicator arrives calibrated for every possible weighing platform. Calibration requirements depend on the connected equipment and its installation.
Routine Care and Troubleshooting
Regular inspection can help prevent inaccurate readings and unnecessary downtime.
- Keep the display and controls clean and readable.
- Charge the battery according to the manufacturer's instructions.
- Inspect cables for cuts, crushed sections or damaged connectors.
- Check for loose electrical connections.
- Keep moisture and debris away from unprotected connections.
- Inspect the platform and weigh bars for binding or interference.
- Recheck calibration when equipment is moved, repaired or readings become inconsistent.
What if the Weight Reading Is Unstable?
First check whether the animal or load is moving. Then inspect the platform for contact with nearby structures, uneven support or mechanical binding.
If instability continues, examine the electrical connections, load-cell cables and indicator settings using the troubleshooting procedures in the operating manual.
What if the Indicator Does Not Return to Zero?
Confirm that the platform is unloaded and that no debris or mechanical interference is applying force to the weigh bars.
Follow the manufacturer's zeroing procedure. Persistent problems may require inspection or recalibration.
Operating Manual
The original product listing provides the following manual for reference:
MTI-500 Weigh Bar Operation Manual (PDF)
Confirm that the manual corresponds to the indicator and weigh-bar configuration being used before following model-specific instructions.
Frequently Asked Questions
Is this a complete livestock scale?
No. This product is a digital weight indicator intended for use with compatible weigh bars or load cells. A complete weighing system requires suitable load-sensing equipment and an appropriate platform or chute arrangement.
Can it be used to weigh cattle?
Yes, when connected to a compatible livestock weighing system that is properly installed and calibrated for the intended load.
Does the indicator have a rechargeable battery?
Yes. The original product specifications identify a rechargeable battery.
Can the indicator display pounds and kilograms?
Yes. The listed controls include lb/kg selection.
Does it support tare and net weight?
Yes. The original specifications list zero, gross, net and tare functions.
How many load cells can it support?
The listed electrical specifications indicate support for up to four 350-ohm load cells. Confirm wiring and system compatibility before connecting equipment.
Can I connect the indicator to a computer or printer?
The original listing describes a serial output for compatible external equipment. Confirm the actual interface standard, cables, communication settings and receiving device compatibility.
Will this indicator work with my existing weigh bars?
Compatibility depends on the electrical specifications, connectors, wiring and calibration requirements of the existing weigh bars. Confirm these details before ordering.
Is the stainless steel indicator waterproof?
The original specifications identify 304 stainless steel construction but do not establish a waterproof rating. Follow the manufacturer's environmental and cleaning instructions.
Choosing the Right Livestock Weighing Equipment
A digital indicator is an important part of a dependable livestock weighing system, but it should be selected together with compatible load cells and a properly designed weighing platform.
Before ordering, identify your existing equipment, load-cell specifications, connector requirements, and intended weighing application.
For additional components and complete systems, browse Barn World's livestock scales and weighing equipment.
If you need assistance identifying the correct indicator or matching it to an existing chute scale, contact Barn World with the equipment model and available specifications.
